Twin screw extruder
PRODUCT PARAMETERS
JED SCREW 杰德螺杆
Description
JEDZS series conical twin-screw plastic extruder, has forced extrusion,high quality, wide adaptability,long service life, small shear rate, material is difficult to decompose, good mixing plasticizing performance, direct powder-molding and so in the characteristics equipped with DC speed regulation, Automatic temperature, vacuum exhaust device. Twin-screw extruder is a type of equipment used in processing plastics, rubber, food, pharmaceutical and chemical industries. They are commonly used in plastic production, such as the production of plastic pipes, sheets, films, granules, etc. Twin-screw extruders are also widely used in the food processing industry to make various foods, such as noodles, puffed foods and candies. In the pharmaceutical and chemical industries, twin-screw extruders can also be used to produce pharmaceuticals, cosmetics and chemical products.
Main Features
1.The soft plastic design concept,ensures the quality of material.
2.Very reliable and effective design theory,ensures the extrusion operation.High torque special drive system,gear,shaft for high strength alloy steel,carburizing,abrasion resistance treatment.
3.The new development of the screw,suitable for formulation of the high amount of filler,guarantee the material in screw good filling degree and the best distribution of material flow.
4.Screw with core temperature reguating device and a well barrel cooling,ensure the accurate control of the temperature of material process.
5.Match different dies and materials for extrusion molding all kinds of pipe,profile and soft(hard)PVC granulation.
Product Parameters
| Project/model | JEDZS 51 | JEDZS 65 | JEDZS 80 | JEDZS 92 |
| Screw diameter (mm) | 51/105 | 65/132 | 80/156 | 92/188 |
| Screw quantity | 2 | 2 | 2 | 2 |
| Screw turning | Different to outside counter-rolation | outward | ||
| Screw rotational speed (rpm) | 2-32 | 1-32 | 1-32 | 1-32 |
| Screw effective length (mm) | 1070 | 1441 | 1800 | 2500 |
| Structural style | Cone meshing | |||
| Main electrical machinery power (kW) | 22 | 37 | 55 | 90 |
| Total power (kW) | 40 | 67 | 90 | 120 |
| Max.extrusion | 120 | 300 | 400 | 800 |
| Barre heating segment number | 4 | 4 | 4 | 5 |
| Heating methods | Screw quantitative | |||
| Screw center height (mm) | 1000 | 1000 | 1000 | 1000 |
| Weight (kg) | 3200 | 4000 | 5000 | 7000 |
| Dimensions (mm) | 3000×1050×2200 | 4230×1520×2450 | 4750×1550×2460 | 6700×1560×2820 |
FAQs
What types of products can we offer?
Product Category:
| Sheet extruder screw cylinder | Blow film extruder screw barrel | Blow molding extruder screw barrel | Recycling granulation extruder screw cylinder |
| Wire and cable extruder screw | Plastic steel strip extruder screw barrel | Wire drawing extruder screw barrel | Film coated extruder screw barrel |
| Cast film extruder screw tube | Plate extruder screw barrel | Spinning extruder screw barrel | Conical twin-screw tube |
| Parallel twin-screw barrel | Injection molding machine screw cylinder | Food extruder screw tube | Chemical extruder screw barrel |
| Non standard screw cylinder | Customized extruder | ||
If some screw products do not have a list, please feel free to contact us by email and we will reply within 24 hours!
What logistics do we ship through?
We can quickly reach any country and region through sea freight, air freight, international express delivery, and other transportation methods. We have stock of standard sized screws and barrels, and once confirmed by the customer, they can be delivered within 5-7 days.
Can it be customized as per our requirements?
We have many experienced engineers who can quickly customize various types and types of screw barrel according to customer requirements. Before produce, technical will check every detail with salesman according with clients’ request. Under produce, every step will be inspected before next process. And every salesman will follow some time to make sure 100% correct and reduce communication error and work undelay. We put quality at a high level and the price is middle level.
What is our ordering process?
What services are included in the after-sales service?
Our sales team is familiar with the production and export processes and has nearly 10 years of customer service experience. Every salesperson can ensure that the customer’s requirements and our screw barrel are 100% accurate in production details. We will solve any cargo issues until the customer is satisfied.
